PolyLite ASA Technical Data Sheet
PolyLite ASA Technical Data Sheet
Product Identification
| Product Name |
PolyLite ASA |
| Product Use |
3D Printing Filament |
| Manufacturer/Supplier |
JF Polymers (Suzhou) Co., Ltd. |
| Address |
2901 Auburn Rd, Auburn Hills, MI 48326 |
| Contact Email |
info@rev1tech.com |
| Telephone |
+248-707-2950 |
| Emergency Telephone Number |
+248-707-2950 |
General Properties
PolyLite™ ASA is an alternative to ABS with improved weather resistance. Its UV resistance and excellent mechanical properties make it the perfect choice for real-life applications.
Material Properties
| Density |
ISO1183, GB/T1033 |
1.13 g/cm3 at 23°C |
| Melt index |
220°C, 10 kg |
25 g/10min |
| Effect of weak acids |
Resistant |
|
| Effect of strong acids |
Slightly resistant |
|
| Effect of weak alkalis |
Resistant |
|
| Effect of strong alkalis |
Slightly resistant |
|
| Effect of organic solvent |
Not resistant |
|
| Effect of oils and grease |
Resistant |
|
Thermal Properties
| Glass transition temperature |
DSC, 10°C/min |
97.8 °C |
| Vicat softening temperature |
ISO 306, GB/T 1633 |
105.3 °C |
| Heat deflection temperature (1.8MPa) |
ISO 75 |
100.2 °C |
| Heat deflection temperature (0.45MPa) |
ISO 75 |
102.6 °C |
Mechanical Properties
| Young’s modulus (X-Y) |
ISO 527, GB/T 1040 |
2379 ± 157 MPa |
| Young’s modulus (Z) |
|
1965 ± 136 MPa |
| Tensile strength (X-Y) |
ISO 527, GB/T 1040 |
43.8 ± 0.8 MPa |
| Tensile strength (Z) |
|
32 ± 1.8 MPa |
| Elongation at break (X-Y) |
ISO 527, GB/T 1040 |
6.7 ± 0.6 % |
| Elongation at break (Z) |
|
1.65 ± 0.2 % |
Printing Guidelines
- Nozzle temperature: 240 – 260 (℃)
- Build surface material: BuildTak®
- Build plate temperature: 75 - 95 (˚C)
- Cooling fan: OFF
- Printing speed: 30-50 (mm/s)
- Retraction distance: 1 (mm)
- Retraction speed: 20 (mm/s)
The typical values presented in this data sheet are intended for reference and comparison purposes only. They should not be used for design specifications or quality control purposes. Actual values may vary significantly with printing conditions. End-use performance of printed parts depends not only on materials but also on part design, environmental conditions, printing conditions, etc. Product specifications are subject to change without notice.
Each user is responsible for determining the safety, lawfulness, technical suitability, and disposal/recycling practices of Rev1Tech materials for the intended application. Rev1Tech makes no warranty of any kind, unless announced separately, to the fitness for any use or application. Rev1Tech shall not be made liable for any damage, injury, or loss induced from the use of Rev1Tech materials in any application.
